PG Clamp And Connector
- Category： Power fitting
Welcome to OEM and Let us know if you need further details or assistance!
Material: The main body is made of aluminum, and the bolt is hot-dip galvanized steel or Stainless steel.
| Type | Dimension(mm) | ||||
| L | W | H | M | No. of bolt | |
| 25-70mm² | 75 | 40 | 20 | 10 | 2 |
| 70-150mm² | 98 | 54 | 34 | 10 | 3 |
| Up-to 300mm² | 160 | 60 | 32 | 14 | 4 |
| Aspect | BS (British Standards) | IEC (International Electrotechnical Commission) | AS/NZS (Australian/New Zealand Standards) | US Standards (ANSI/IEEE) | GB (Chinese National Standards) |
|---|---|---|---|---|---|
| Voltage Range | Typically up to 36 kV | Up to 52 kV | Up to 36 kV | Up to 46 kV | Up to 40.5 kV |
| Material Specifications | Specifies materials for durability and safety | General material guidelines for international use | Similar to IEC with local adaptations | Detailed material specs for US market | Follows IEC with local modifications |
| Testing Requirements | Includes type, routine, and sample tests | Comprehensive testing for safety and performance | Aligns with IEC but includes local conditions | Rigorous testing for safety and reliability | Similar to IEC with additional local tests |
| Application Guidelines | Detailed installation and usage guidelines | Broad guidelines for international applicability | Specific to Australian and New Zealand conditions | Focused on US electrical systems | Tailored to Chinese electrical systems |
| Safety Standards | High emphasis on safety and reliability | Global safety standards | High safety standards with local regulations | Stringent safety protocols | Strong focus on safety and compliance |
| Certification | Kitemark certification | CB Scheme for international certification | Local certification bodies | UL, CSA, and other US certifications |
CCC (China Compulsory Certification) |
